The Astera AX1 Pixeltube is a powerful pixel controllable RGBW LED baton that can be mounted at event and film sites to light up people and objects or create indirect lighting effects. The Astera AX1 Pixeltube is a highly creative device that offers an infinite range of possibilities.
The Astera AX1 is an IP65 outdoor rated, waterproof, pixel controllable, decorative LED RGBW baton that can be mounted or used anywhere. While the Astera AX1 Pixeltube is designed primarily for event use, the Astera AX1 could be used by filmmakers as either a substitute for practical light sources, or for special effects.
The Astera AX1 Pixeltube lights work with a specially optimized RGB color space: AsteraRGB. This system eliminates the need to control each color individually. Instead, the light calculates the optimum combination of all colours based on an RGB value. It considers each LED chip’s temperature as well as an optimal color rendering.
The Astera AX1 only draws 28W of power. This enables the light to be run continually for up to 20 hours via its in-built Samsung lithium-ion battery. Once exhausted, the battery takes seven hours to charge – and if that leaves you in a predicament, the Astera AX1 can also be powered by mains electricity. The light generates a 180° beam angle, but only puts out 696lx.
The Astera AX1 lights are constructed out of polycarbonate, and feature metal end caps. They weigh 2.2Lbs and are 103.5cm (40.7″) long with a 4.2cm (1.6″) circumference.
The Astera Pixeltube offers several mounting options. For a quick vertical setup an included stand can be screwed via its M5 thread onto the tube. For hanging the tube there are hangers that can be fixed with screws to wooden surfaces or fixed to truss via a 1/4” Manfrotto stud and a Manfrotto clamp.
Astera AX1-SET PixelTube Pack Includes:
8 – Astera AX1 Wireless Pixeltube
1 – Astera AX1-CHRCSE Charging Case
1 – Astera Power Cord for the Charging Case
All Astera AX1 Accessories (8 x stands, 16 x holders x 16 spigots, 16 x eye bolts)
Astera ARC1 Remote Control is NOT included (you will need these to use the lights!)
Astera AX1 Optical Specifications:
28W RGBW LEDs – 180° Beam Angle
Colors: RGBW
Total LED power: 28W
Lumens: 695Lm
CRI: up to 88
Strobe: 0-25Hz
Beam Angle: 180˚
Pixels: 16
Astera AX1 Electrical Specifications:
Battery: LG Chem Lithium-ion
Battery Lifetime: 70% after 300 cycles
Battery Runtime: Up to 20 hours
LED Lifetime: 50.000 Hours
Charging time (nominal): 7 Hours
Input Voltage (charger): 90-264V 47-63Hz
Input Voltage (Light): 48V 0.5A
Astera AX1 Control Specifications:
Wireless Modules: 865-870MHz | 902-928MHz | 2.4GHz
Range: 300m | 330 Yards
DMX: Supports CRMX and W-DMX
Astera AX1 Construction
Housing: Polycarbonate, metal endcap
IP Rating: IP65
Relative humidity: 0-100%
Operating Temperature: 0-40 ˚C | 32-104 ˚F
Weight: 1kg |2.2Lbs
Dimensions: Ø42 x 1035mm | Ø1.6” x H40.7”
Astera Product Features
Talkback+
Detect all available lights, set them up, check their status, configure DMX addresses and DMX profiles.
Seamless runtime
Set the length of your event and be sure that your lights won’t run out while still getting the maximum brightness.
TruColor calibration
100% color consistency through any batch. It can hit exact color temperatures and reproduce standard filter gels.
Flicker free
The AX1 scrambles the PWM frequency so you can be sure that there won’t be interferences when recording video.
Anti-theft
The lights give visual and audible alarm and send notification to the AsteraApp if they are being moved during an event.
DJ feature
Auto BPM analyzes the beat and matches programs to it, flash buttons can trigger special effects while being held down.
Scheduled stand-by
Switch lights into power-saving standby and schedule them to wake up when the event starts.
Dynamic power-boost
The dynamic power-boost feature enables the light to display the maximum brightness at all times and intensify non-white colors.
Emergency light
Switches automatically to white light and runs of its battery when AC power is cut off.
Weight 65 lbs
Dimensions 45 x 18 x 7 in
Advanced Media is ASTERA LED authorized distributor. Contact Advanced Media Dubai for Astera Set of 8 AX1 with Charging Case
