| Standards |
| SDI Video Input |
1x 12G-SDI SD/HD/2K/4K auto switching |
| SDI Video Output |
1x 12G-SDI loop output |
| Analog Video Output |
Component SD/HD, NTSC, PAL, and S‑Video |
| Analog Audio Output |
2 channels professional balanced analog audio via XLR connectors
Right XLR can be configured for timecode output |
| AES/EBU Audio Output |
4 channels professional 110 ohm balanced digital audio via XLR connectors
Right XLR can be configured for timecode output |
| Multi Rate Support |
Automatic switching between SD/HD/2K and 4K |
| Updates and Configuration |
USB or Ethernet |
| Re-Clocking |
Yes |
| SD Format Support |
525/29.97 NTSC, 625/25 PAL |
| HD Format Support |
1280 x 720p50, 1280 x 720p59.94, 1280 x 720p60, 1920 x 1080i50, 1920 x 1080i59.94, 1920 x 1080i60, 1920 x 1080PsF23.98, 1920 x 1080PsF24, 1920 x 1080p23.98, 1920 x 1080p24, 1920 x 1080p25, 1920 x 1080p29.97, 1920 x 1080p30, 1920 x 1080p50, 1920 x 1080p59.94, 1920 x 1080p60 |
| 2K Format Support |
2048 x 1080PsF23.98, 2048 x 1080PsF24, 2048 x 1080PsF25, 2048 x 1080p23.98, 2048 x 1080p24, 2048 x 1080p25 |
| 4K Format Support |
3840 x 2160p23.98, 3840 x 2160p24, 3840 x 2160p25, 3840 x 2160p29.97, 3840 x 2160p30, 3840 x 2160p50, 3840 x 2160p59.94, 3840 x 2160p60, 4096 x 2160p23.98, 4096 x 2160p24, 4096 x 2160p25, 4096 x 2160p29.97, 4096 x 2160p30, 4096 x 2160p50, 4096 x 2160p59.94, 4096 x 2160p60 |
| SDI Compliance |
SMPTE 292M, SMPTE 259M, SMPTE 296M, SMPTE 372M, SMPTE 424M-B, SMPTE 425M, ITU-R BT.656, and ITU-R BT.601 |
| SDI Video Rates |
SDI video connections are auto switching between SD-SDI, HD-SDI, high definition level B 3G-SDI, 6G-SDI, and 12G-SDI |
| SDI Video Sampling |
4:2:2 and 4:4:4 |
| SDI Audio Sampling |
Television standard sample rate of 48 kHz and 24-bit |
| SDI Color Precision |
4:2:2 and 4:4:4 |
| SDI Color Space |
YUV |
| Analog Format Support |
525/29.97 NTSC, 625/25 PAL, 1280 x 720p50, 1280 x 720p59.94, 1280 x 720p60, 1920 x 1080i50, 1920 x 1080i59.94, 1920 x 1080i60, 1920 x 1080p23.98, 1920 x 1080p24, 1920 x 1080p25, 1920 x 1080p29.97, 1920 x 1080p30, 1920 x 1080p50, 1920 x 1080p59.94, 1920 x 1080p60 |
| Analog Color Space |
REC 601, REC 709 |
| Analog Color Precision |
YUV 4:2:2 and RGB 4:4:4 in HD, 2K, and 4K |
| Format Conversion |
HD down conversion |
| Software Control |
Mac OS X and Windows software upgrade via USB and Ethernet |
| Internal Software Upgrade |
Via included updater application |
| Basic Settings Control |
Mini Switches, USB, and Ethernet via free software utility |
| Power Supply |
1x built-in international AC power supply with IEC C14 inlet
IEC power cable required (not included)
90 - 240 VAC input |
| Power Over Ethernet |
Can be powered via 48 VDC using PoE (Power-over-Ethernet) |
| Power Consumption |
15 W |
| Operational Voltage Range |
90 - 240 VAC |
| Operating Temperature |
32 to 104°F (0 to 40°C) |
| Storage Temperature |
-4 to 140°F (-20 to 60°C) |
| Relative Humidity |
0 to 90% non-condensing |
|
